Conveyor Roller Milling Shaft Machine

Conveyor Roller Milling Shaft Machine

Conveyor Roller Milling Shaft Machine is used for the synchronous processing for the flat and groove at both ends of the roller shaft.
Four sets of milling devices work simultaneously to guarantee the symmetry of the flat and groove of the roller shaft.

Introduction to Conveyor Roller Milling Shaft Machine

Product Overview

Conveyor Roller Milling Shaft Machine in modern hardware intended to smooth out material taking care of and handling tasks with unrivaled effectiveness. This complex hardware is fastidiously created to fulfill the demanding needs of present day businesses, offering a strong answer for different processing applications.

Product Standards

Our Transport Roller Processing Shaft Machine is carefully intended to agree with rigid industry norms, ensuring ideal execution and unwavering quality in modern tasks. By sticking to these thorough principles, for example, ISO 9001 for quality administration frameworks and ANSI/ASME for security conventions and hardware particulars, our machine guarantees predictable and productive processing processes. The emphasis on satisfying industry guidelines highlights our obligation to conveying first rate items that address the issues of our clients while focusing on wellbeing and quality. With our Transport Roller Processing Shaft Machine, clients can confide in its strength, accuracy, and adherence to the most noteworthy industry benchmarks.

Product Attributes

  • Precision Engineering: Each component is precision-engineered to deliver consistent performance and durability.

  • Versatility: Adaptable to a wide range of materials and milling requirements.

  • Durability: Constructed from high-quality materials to withstand rigorous industrial environments.

  • Efficiency: Optimized design ensures maximum throughput and minimal downtime.

  • User-Friendly: Intuitive controls facilitate easy operation and maintenance.

Product Functions

The product facilitates the seamless milling of various materials, ranging from grains to industrial products. Its robust conveyor system efficiently transports materials to the milling chamber, where precision rollers ensure uniform processing, resulting in superior quality output.

Features

  • Advanced Conveyor System

  • Precision Rollers

  • Adjustable Parameters

  • Modular Design

  • Safety Features

Advantages and Highlights

  • Enhanced Efficiency: Streamlines material handling and milling processes, increasing productivity.

  • Superior Quality Output: Precision milling ensures consistent quality and particle size distribution.

  • Customization Options: Tailored to meet specific requirements, ensuring optimal performance.

  • Reliability: Engineered for durability and reliability, minimizing maintenance and downtime.

Application Areas

The product finds applications across diverse industries, including:

  • Food Processing

  • Pharmaceutical

  • Chemical

  • Agricultural

  • Manufacturing

OEM Service

We offer comprehensive OEM services, allowing customization to meet unique specifications and branding requirements.

FAQ

Q: Can the product handle abrasive materials?

A: Indeed, our machine is intended to deal with different materials, including rough ones, effortlessly.

Q: What sort of support does the machine require?

A: Ordinary investigation and oil of moving parts are prescribed to guarantee ideal execution and life span.

Contact Information

For inquiries or to place orders, please contact us at: angie@idlerchina.com.

Conclusion

In summary, it represents a cutting-edge solution for material handling and processing needs. With its advanced features, superior performance, and customizable options, it stands as a cornerstone of efficiency and reliability in industrial operations worldwide.

Conveyor Roller Milling Shaft Machine Parameter

spindle speed

130r/min

roller shaft dia

φ20—φ40

roller shaft length

200—2300mm

shaft groove and flat width

6—30mm

milling depth

0—5mm

spindle motor

3kw*2(sets)

pump motor

1.5kw

hydraulic system working pressure

4—6mpa

hydraulic system flow

31L/min

cooling pump motor

40w

Dimension

4000×1500×1440mm

Hydraulic Station

540x540x600mm

Distribution Box

320x500x770mm

Production efficiency

260 pcs/ hour,14 seconds/pc
